Lefaucheux revolver Model 1854 explained (ebook)

[gerard]

Recently published at HLebooks.com

This e-book is downloadable here : http://www.hlebooks.com/ebook/lf1854en.htm

Android version at Google Play: https://play.google.com/store/apps/d...books.lf1854en

Ebook's Content

Field stripping of the Lefaucheux 1854
- Lefaucheux model 1854 of Belgian manufacture
- Lefaucheux model 1854 of French manufacture
- Locking of the barrel underlug in the French manufacture
- Dismounting of the barrel
- Cylinder slipped out of its axis pin
Advanced dismounting of the Lefaucheux 1854 (1)
- Dismounting of the ejector rod
- Removal of the grip plates
- Dismounting of the grip rear band
- Dismounting of the lanyard ring
- Variations of the butt plate
Advanced dismounting of the Lefaucheux 1854 (2)
- Dismounting of the mainspring
- Dismounting of the cylinder stop
- Dismounting of the trigger guard piece
Advanced dismounting of the Lefaucheux 1854 (3)
- Dismounting of the hammer
- Dismounting of the trigger
- Dismounting of the loading gate
Functioning of the Lefaucheux 1854 (1)
- The pinfire cartridge of 12 mm
- 12 mm pinfire French service cartridge
- Modern reloading kit for pinfire cartridges
- User manual of the kit
Functioning of the Lefaucheux 1854 (2)
- Loading of cartridges in the cylinder
- Cartridge with its pin misaligned
- One drawback of the pinfire system
- Variation of the headspace
- Crushing of the cartridge against the recoil shield
- Hammer set to the safety notch or not
- Carrying the gun with six cartridges loaded
- Hammer positioned between two firing pins
- Unloading of the cartridges
Functioning of the Lefaucheux 1854 (3)
- Hammer put at the **** notch
- Action of the hand on the cylinder ratchet
- Functioning of the cylinder stop
- Weakness of the cylinder locking
- Cylinder stop integral with the trigger
Markings of the Lefaucheux 1854
- Lefaucheux at Paris usual markings
- Lefaucheux at Liege (Belgium) usual markings
- Saint-Etienne arsenal markings
- DIRECTORS OF THE MAS
Evolution of the Lefaucheux 1854
- Initial variation following patent #19380 of June 10, 1854
- Second variation of the 1854 model
- Third variation of the 1854 model
- Model 1854 of Belgian manufacture
The Lefaucheux 1858 of the French Marine
- Model 1858 of the French Marine
- Model 1858 redirected to the commercial market
- Model 1858 N of the French Marine
- Model 1858 N T of the French Marine
Foreign contracts and special models
- Lefaucheux 1854 for Spain
- Lefaucheux 1854 for Italy
- Lefaucheux 1854 for Russia
- Lefaucheux 1854 for Egypt
- Lefaucheux 1854 for Sweden
- Lefaucheux 1854 for Norway
